MAXI-LITE® II V-Series® 6-Light

MAXI-LITE® II V-Series® 6-Light



 The Maxi-Lite® II V-Series® 6-Light provides 813,000 lumens of light from the standard 6 light arrangement. With up to 20 kW or power, this light tower has plenty to spare for powering up additional 120 or 240 volt equipment on your jobsite. 100 gallons of fuel capacity provides up to 227 hours of run-time (when equipped with LED fixtures), and the twin large, 4 inch diameter fuel fill necks allows for fast refueling from either side of the machine. Standard fluid containment means you don't have to worry about accidental spills damaging the environment, and the large rear drain makes it easy to clean out should an accident occur. Combine all this with Allmand reliability, and you have a light tower that is hard to beat.

SLS Sequenced Light System





(2) 50 Gallon Polyethylene Fuel Tanks





Full Fluid Containment System





Five-Point Stabilizer System





Below-the-Frame Forklift Pockets





Lifting Ring





Removable Drawbar





Gull-Wing Style Doors





External Oil and Engine Coolant Drain




Download the product spec sheet for additional information.




Engine Brand Caterpillar
Engine Model C1.1
EPA Emission Level Tier 4 Final
Prime Output @ Rated Speed of 1800 RPM (HP)** 13.3
Prime Power 8
Engine Electrical System 12V; Glow plug cold starting
Battery (CCA @ 0° F - Standard) 550
Fuel Capacity 100
Operatine Time (hrs) (using four 1,250 W metal halide light fixtures) N/A
Operating Time (hrs) (using four 320 W LED light fixtures) 228
Number of Luminaires - Metal Halide N/A
Light Type N/A
Wattage N/A
Lumens (per lamp) N/A
Lumens (total) N/A
Number of Luminaires- LED's 6
LED Light Type Two LED, 5000° K color temperature
LED Wattage 320
LED Lumens (per lamp) 38,500
LED Lumens (total) 231,000
Lighting Features Sequenced Lighting System (SLS™). System automatically turns on lights after engine start and delays engine shutdown to turn off lights first to prevent generator from shutting down while under load.
Generator (Alternator) Standard-120/240 VAC automatic voltage regulation
Frequency (Hz) 60
Phase 1
Outlets Standard - (2) 20 A 120 VAC duplex GFCI outlets, (3) 30 A 240 VAC 4-Wire Twist Lock (NEMA L14-30R), (1) 50 A 240 VAC RV (NEMA L14-50R)
Tower Maximum Height 332
Tower Features Structure - six section tubular steel design Actuation - hydraulic cylinder Guide pads - polyethylene self lubricating Manual winch to raise Balloon Light from installation position to operating position
Power Cable Power cable encased in Nycoil™ flexible tubing
Fixture Positioning Light bar with fixtures can be rotated 359° and fixtures can be adjusted with tower in lowered position.
Towing Connection "Adjustable height combination 2 in. (50.8 mm) ball coupler, 3 in. (76.2 mm) lunette ring for pintle hitch Adjustable height Standard - 2 in (50.8 mm) ball coupler"
Trailer Frame - Formed, welded steel frame Axle - tubular axle with elliptical leaf springs Tires - ST205/75R 15 radial load range 'C' Doors - Stamped steel gull-wing style with lockable latch Standard features - Fluid Containment System (FCS) holding up to 110% of all on-board fluids - Remote engine oil and coolant drain easily accessible at rear of trailer - Forklift pockets - below-the-frame - Lift ring - Tie down rings - Removable tongue
Trailer Lighting Stop, turn, tail lights / side marker lights / illuminated license plate bracket Standard - 4-way flat connector
Operating Wind Speed 65
Stabilizers Five-point design - tongue jack, two retractable side outriggers at front of trailer, two retractable side outriggers at rear of trailer
Shipping Weight 3,430
Gross Vehicle Weight Rating (GVWR) 4,300
Length - Transport Position 127
Length - Outriggers Deployed 167
Width - Transport Position 77
Width - Outriggers Deployed 151
Height Mast Lowered - Transport Position 105
Height - Tower Raised 332
Shipping 7 units on a 48' or 53' flatbed
Options Arctic Package - Heavy duty battery - Block heater (120 VAC) - Interior work light - Arctic hydraulic fluid Arctic Max Package (Only available with Arctic Package) - Heated fuel / water separator - Radiator cover - Low fuel beacon - Adjustable air vent cover panels - Diesel fired block heater - Dual heavy duty batteries - LSC With E-Stop Package LED Package - (6) LED Light FIxtures LSC With E-Stop Package - LSC 2.1™ - Light Sensing Commander® - Automatically starts engine at sunset and shuts down engine at sunrise - programmable - Emergency Stop switch on exterior of machine AirStar Package Balloon Light features the Airstar Flex diffused lighting system using Allmand’s exclusive bulbs. This system provides reduced glare while still illuminating a large area. Engine Air Intake Shut-Off Valve 2 in (50.8 mm) Bulldog® Coupler Telematics Custom Paint Skid Mount available on Standard SKUs
Manuals DownloadIllustrated Parts List - English
DownloadWiring Diagram Schematic - English
DownloadInstruction Sheet - English, Spanish, French
DownloadOperator's Manual - English, Spanish, French
DownloadIllustrated Parts List - English
